David Pipes and Tubes, located in Canberra, Australia, stands out as a top manufacturer and supplier of Nickel Alloy Tubing. Renowned for its exceptional quality, precision, and durability, this tubing is designed to resist corrosion, boast high mechanical strength, and perform reliably in extreme conditions. Crafted using advanced seamless and welded techniques, it guarantees consistent wall thickness, smooth internal surfaces, and precise dimensions. Perfect for applications in chemical, petrochemical, marine, and power generation sectors, David Pipes and Tubes offers Nickel Alloy Tubing in a variety of grades and specifications tailored to meet the needs of critical and high-temperature systems.
The composition of Nickel Alloy Tubing primarily includes nickel, along with varying levels of chromium, iron, and molybdenum, depending on the specific alloy grade, such as Inconel, Monel, or Hastelloy. This unique blend provides remarkable resistance to oxidation, corrosion, and scaling in acidic, alkaline, and high-temperature settings. With a tensile strength ranging from 550 to 900 MPa, it also showcases excellent ductility and thermal stability. The tubing maintains its mechanical integrity even under pressure and heat, making it a dependable choice for demanding industrial applications.
| Nickel Pipe sizes range | 1/8”NB to 30”NB (Nominal Bore Diameter, ie the inner diameter of the pipe) |
| Manufacturer of | Seamless, Welded, Electric Resistance Welded (ERW), Fabricated, or LSAW |
| Form of | Round, Hydraulic, Rectangular, or Square |
| Marking | All Nickel Alloy pipes & tubes are marked as: Manufacturer Name, Standard, Grade, Thickness, OD, Length, Heat No. (Or according to the customer’s request.) |
| Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Pipe End | POE, TOE, TBE, BOE, BOE, PBE, BLE, BSE, BBE, BE, Plain End, Beveled End, and Treaded |
| Nickel Alloy Tubes | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| Alloy 200 Tube | 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Alloy 201 Tube | Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Nickel Based Alloys | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Alloy 200/ 201 Tube | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Nickel Alloy Tubing from David Pipes and Tubes ensures high quality and durability, as these tubing offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in nickel alloy products ensures you receive a top-tier solution tailored to your needs.
David Pipes and Tubes, one of the largest suppliers of Nickel Alloy Tubing in Canberra, Australia, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for nickel alloy products in the region.
| Wall Thickness (WT) | Nickel Tube Size Chart ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
Yes, we offer custom sizes for Nickel Alloy Tubing to meet your specific requirements. Our team at David Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@davidpipes.com.
Nickel Alloy Tubing finds extensive use in heat exchangers, condensers, chemical processing systems, power generation equipment, marine engineering, and aerospace applications. It excels in environments that involve strong acids, saline solutions, and high temperatures. Its combination of strength, corrosion resistance, and durability makes it the go-to option for industries that require reliable and long-lasting tubing solutions in extreme conditions.
